SDI optical transceiver adopts advanced uncompressed digital high-definition video and high-speed digital optical fiber transmission technology, which can easily transmit SDI high-definition signals to the far end over a long distance, with strong anti-interference ability, ensuring signal integrity and stability.
1.All digital, uncompressed HD fiber transmission
2.Support full HD, 1920 * 1080 @ 60
3.Optical interface SFP (LC) optical attenuation -3db
4.1 channel analog audio / 1 channel RS232 / 1 channel RS485,
5.Compatible with SD-SDI, HD-SDI, 3G-SDI standards
6.Automatically identify and configure various display modes
7.Built-in automatic equalization, the picture is clear and stable
8.Built-in ESD protection circuit, can effectively prevent electrostatic damage
9.On-site installation: simple and convenient, plug and play, no setting required
|
Name
|
Description
|
|
Video
|
Interface
|
SDI
|
|
Protocol
|
SDI
|
|
Pixel bandwidth
|
165MHz
|
|
Resolution
|
SD-SDI:
576I 480I
HD-SDI:
720P50 720P60
1080P24 1080P25
1080P30
1080I50 1080I60
3G-SDI:
1080P50 1080P60
|
|
Audio
|
Interface
|
Industrial terminal
|
|
Format
|
44.1K,48K,96K,176K,192K
|
|
RS232
|
Interface
|
Industrial terminal
|
|
Baud rate
|
115200 Backward compatible
|
|
Data bit
|
8bit
|
|
Optical fiber
|
Interface
|
LC
|
|
Type
|
SFP Single mode
|
|
Wavelength
|
1550/1310nm
|
|
Bandwidth
|
3Gbps
|
|
Distance
|
10KM 20KM 40KM 60KM 80KM Optional
|
|
Attenuation
|
-3db
|
|
Other
|
Temperature
|
-20~ +75°C
|
|
Humidity
|
5 ~ 90 %
|
|
Power consumption
|
4W/pcs
|
|
Power supply
|
DC 12V1A，Inside positive outside negative
|
