Product Introduction:
This set of equipment includes a sender and a receiver, which can transmit VGA video and audio signal of PC to a remote location over single network cable, the device supports HD video transmission at 1920×1080@60Hz resolution, it support POE.
This product can be widely used in video conference system, multimedia display system, medical display system, commercial presentation system etc.
Product Feature:
1, Max video resolution 1920×1080@60Hz
2, Transmitter connected to an external power source, the receiver via POE power supply, transmission distance of 180 meters; receiver is connected to an external power supply, transmitter powered by POE, the transmission distance is 80 meters.
3, Single network cable transmission, pure hardware design, no need software driver
4, No need to do any setting
Product Specification:
Function
|
Input signal
|
1-ch VGA and 1-ch AUDIO
|
Output signal
|
Sender: 1-ch VGA
Receiver:1-ch VGA+ 1-ch AUDIO
|
Video and interfaces
|
Video input
|
HD15PIN (male VGA)
|
Video output
|
HD15PIN (female VGA)
|
Video bandwidth
|
>350MHz(-3dB)
|
synchronized signal
|
>200KHZ
|
Video resolution
|
1080p
|
Audio
|
3.5mm stereo audio
|
RJ-45
|
Cat 5E/Cat6
|
Physical
|
Size(L×W×H)
|
Sender: 108mm×74mm×30mm
Receiver: 108mm×74mm×30mm
|
N.W
|
0.5Kg
|
Case
|
Aluminum
|
Color
|
Silver
|
Power supply
|
Voltage
|
DC 12V/2A
|
power consumption
|
<15W
|
Environment
|
Working temperature
|
-15℃-55℃
|
Storage temperature
|
-40-80℃
|
Humidity
|
0-95% (Non-condensing)
|
