HDV2-100D(HDMI2.0 100m optical fiber extension cable)

Share to：

Product Introduction

HDMI 2.0 passive optical fiber extension cord adopts advanced embedded optical engine technology, support 18Gbps transmission speed，support HDMI 2.0 protocol, and provide excellent HDMI signal integrity，transmission distance have 10m、30m、60m、100m four standards for choose，plug and play, no need external power supply .Product can be used in the field of video conference, multimedia information distribution, government, medical system, commercial display, multimedia function hall, utilities and so on.

Product Features
◆Maximum 100m transmission distance
◆Completely support HDCP2.2 bi-directional EDID & HDCP communication
◆Support 4K×2K@60HZ,3D
◆Low power consumption(maximum 250mW),no need external power supply
◆Total bandwidth can reach 18Gbps
◆Plug and Play，don't need any Settings

Product specifications
◆HDMI version: HDMI 2.0
◆HDCP & DDC: HDCP 2.0 Complete support the bidirectional EDID and HDCP communication
◆Video bandwidth: maximum 6Gbps*3 channel+600MHz pixel clock
◆Resolution: 4K×2K@60HZ
◆Connector types: HDMI A male
◆HDMI（OD）: 4.0mm
◆Power supply: No need external power supply

Model list：

Model	Transmission distance	Signal types	Select
HDV2-10D	10m	HDMI	□
HDV2-30D	30m	HDMI	□
HDV2-60D	60m	HDMI	□
HDV2-100D	100m	HDMI	□
