Power
|
Voltage
|
AC220V
|
|
Power consumption
|
20W
|
|
Video
|
Video input connector
|
VGA/HDMI
|
|
VGA
|
Female 15pin VGA connector
|
|
HDMI support
|
HDMI1.1 1.2 1.3
|
|
HDCP support
|
HDCP1.2
|
|
HDMI resolution
|
1080p/1080i/720p/720i/576p/576i/480p/480i
|
|
Video color format
|
24bit/30bit deep color/36bit deep color
|
|
Audio format
|
DTS/HD/Dolby-tureHD/LPCM7.1/DTS/Dolby-AC3/DSD
|
|
Transmission rate
|
1Gbps
|
|
Input/Output TMDS signal
|
0.5-1.5Vp-p(TTL)
|
|
Input/Output DDC signal
|
5Vp-p(TTL)
|
|
Input cable length
|
≤20m AWG26 HDMI 1.3 standard cable
|
|
Output cable length
|
≤20m AWG26 HDMI 1.3 standard cable
|
|
USB
|
Protocol
|
Support USB1.1, compatible 2.0 protocol USB device
|
|
Audio
|
|
Sender with USB, receiver is USB-to-Audio sound card type
|
|
Optical
|
Data Transfer Rate
|
1.65Gbps
|
|
Input optical wavelength
|
SM(1310nm,1550nm)
|
|
Transmitting power
|
-9.5~-3dBm @1310nm average
|
|
Optical receiving sensitivity:
|
-23dBm @1310nm average
|
|
Connector type
|
FC
|
|
Transmission distance
|
1m~20KM (SM fiber)
|
|
Housing
|
Size（L× W×H）
|
425mm*210mm*45mm
|
|
Material
|
Metal
|
|
Color
|
Black
|
|
N.W.
|
2.5Kg
|
|
Environment
|
Working temperature
|
-15℃-55℃
|
|
Storage temperature
|
-40-80℃
|
|
Humidity
|
0-95% (Non-condensing）
|
