Product Introduction:
This set of equipment includes a sender and a receiver, which can transmit HDMI video signal to a remote location over single Cat5e or Cat 6 cable, so that user can see the real-time picture image remotely.
It support HDMI signal transmission at max 1920 * 1080 @ 60Hz, Support POE.
The product can be widely used in military command and control system, police command and control system, traffic management system, energy and electricity supply industry, government office, medical system, commercial presentation, multimedia and public utilities etc.
Product feature:
1,Support 1920×1080@60Hz
2,Transmitter connected to an external power source, the receiver via POE power supply, transmission distance of 150 meters; receiver is connected to an external power supply, transmitter powered by POE, the transmission distance is 130 meters.
3,Single network transmission, pure hardware design, no driver needed, compatible with all operation systems, support plug and play.
Product specification:
Video
|
I/O connector
|
HDMI
|
|
HDMI version
|
HDMI1.1 1.2 1.3
|
|
HDCP
|
HDCP1.2
|
|
HDMI resolution
|
1080p/1080i/720p/720i/576p/576i/480p/480i
|
|
Video color format
|
24bit/deep color 30bit/deep color 36bit
|
|
Audio format
|
DTS/HD/Dolby-tureHD/LPCM7.1/DTS/Dolby-AC3/DSD
|
|
TMDS
|
0.5-1.5Vp-p(TTL)
|
|
DDC
|
5Vp-p(TTL)
|
|
Physical
|
Size (L× W ×H)
|
Sender : 93mm*74mm*30mm
Receiver: 93mm*74mm*30mm
|
|
N.W.
|
0.3Kg
|
|
Power
|
Voltage
|
DC12V/2A
|
|
Power consumption
|
<12W
|
|
Environment
|
Working temperature
|
-15℃-55℃
|
|
Storage temperature
|
-40-80℃
|
|
Humidity
|
0-95% (non-condensing)
|
