function
|
Number of input signal
|
3 port
|
Number of input signal
|
1 port
|
transmission signal
|
HDMI
|
performance
and Interface section
|
Support HDMI version
|
HDMI1.3
|
Support HDCP version
|
HDCP1.2
|
HDMI resolution
|
1080p/1080i/720p/720i/576p/576i/480p/
480i,1920×1200@60HZ,4K×2K
|
Support video color format
|
24bit/30bit/36bit /deep color
|
Support audio format
|
DTS/HD/Dolby-ture HD/LPCM7.1/
DTS/Dolby-AC3/DSD
|
Max transmission rate
|
5Gbps
|
Max transmission bandwidth
|
225MHZ
|
In-out TMDS signal
|
0.5-1.5Vp-p(TMDS)
|
In-out DDC signal
|
5Vp-p(TTL)
|
Input cable length
|
≤15m (AWG26 standard cable )
|
Output cable length
|
≤10m (AWG26 standard cable)
|
Control Method
|
Push button/distance type
|
Power section
|
Adaption to the voltage range
|
Input:AC110V-220V,50/60HZ
Output:5V/1A DC
|
Power consumption
|
<3W
|
Property
|
Size(L×W×H)
|
82mm×58mm×18mm
|
Case Material
|
Plastic
|
Color
|
black
|
Weight
|
45g
|
Operating environment
|
Operating temperature
|
-15~55℃
|
Storage temperature
|
-20℃~70℃
|
Humidity(No condensation)
|
0~90%
|
